43BDL5050D/00

5000 Series / D-Line

Go beyond the ordinary. Captivate audiences and elevate their experience with the Philips Signage 5000. Powered by Android 14 for smooth integrations, this versatile 24/7 display steps up to deliver exceptional performance in any setting.

Size: 43”

98” 86” 75” 65” 55” 50” 43” 32”

Get a quote

Connectivity Toggle

Audio output	3.5 mm jack
External control	RJ45, RS232C 2.5 mm jack, IR 3.5 mm jack, Wi-Fi 6, Bluetooth 5.2,
Video output	HDMI 2.0
Other connections	4G/LTE antenna connectors, Micro USB, USB 3.0,
Video input	DisplayPort 1.4, HDMI 2.0, USB-C,

Convenience Toggle

Tiled Matrix	Up to 10 x 15
Energy-saving functions	Smart Power
Keyboard control	Hidden, Lockable,
Signal loop through	RS232, IR Loop through, HDMI1, HDMI 2, Android SoC,
Network controllable	RS232, External 4G mPCIe slot, RJ45,
Screen-saving functions	Pixel Shift
Placement	Landscape, Portrait,

Accessories Toggle

Included Accessories	RS232 daisy-chain cable, Philips logo, AC Switch Cover, USB Cover, Screws, AC Power Cord, IR sensor cable, Quick start guide, Remote control and AAA batteries, RS232 cable, CRD32 Wi-Fi and BT module,

Internal Player Toggle

CPU	4 x A72 + 4 x A53 RK3576 + MT9800
Storage	32 GB
Memory	4 GB RAM
GPU	ARM Mali G52 MC3

Dimensions Toggle

Wall Mount	200 x 200 mm, M6
Set Height	561.2 mm
Bezel width	13.9 mm
Product weight (lb)	23.61 lb
Product weight	10.71 kg
Set Width (inch)	38.31 inch
Set Depth	63.5 mm
Set Width	973.0 mm
Set Height (inch)	22.09 inch
Set Depth (inch)	2.50 inch

Sound

Built-in speakers	2 x 10 W RMS

Power

Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
Consumption	EEI lot5 50 W
Standby power consumption	<0.5 W
Energy Label Class	F

Multimedia Applications Toggle

USB Playback Audio	AAC, HEAAC, MPEG,
USB Playback Picture	BMP, JPEG, PNG,
USB Playback Video	MPEG, H.263, H.264, H.265, AVI, MP4, MPEG4, VP8, VP9, WEBM,

Operating conditions Toggle

Temperature range (storage)	-20 ~ 60 °C
Humidity range (operation)[RH]	20–80% RH
MTBF	50,000 hour
Humidity range (storage) [RH]	5–95% RH
Temperature range (operation)	0 ~ 40 °C
Altitude	0 ~ 3000 m
Ingress protection	IP5X

Miscellaneous Toggle

On-Screen Display Languages	English, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish,
Warranty	3 year warranty
Regulatory approvals	CE, RoHS, CB,

Picture/Display Toggle

Diagonal screen size (metric)	108.0 cm
Brightness	600 cd/m²
Response time (typical)	8 ms
Panel technology	ADS
Operating system	Android 14
Viewing angle (horizontal)	178 degree
Dynamic contrast ratio	500,000:1
Aspect ratio	16:9
Panel resolution	3840 x 2160
Pixel pitch	0.2451 x 2451 mm
Picture enhancement	3/2 - 2/2 motion pull down, Motion compens. deinterlacing, Dynamic contrast enhancement, Progressive scan,
Contrast ratio (typical)	1200:1
Diagonal screen size (inch)	42.5 inch
Haze	25%
Viewing angle (vertical)	178 degree
Display colours	1.07 Billion
Optimum resolution	3840 x 2160 @ 60 Hz

Supported Display Resolution Toggle

Computer formats	1024 x 768, 60 Hz, 1280 x 1024, 60 Hz, 1280 x 720, 60 Hz, 1440 x 900, 60 Hz, 1600 x 900, 60 Hz, 1680 x 1050, 60 Hz, 1920 x 1080, 60 Hz, 640 x 480, 60 Hz, 800 x 600, 60 Hz,
Video formats	1080p, 50, 60 Hz, 1080i, 50, 60 Hz, 480p, 60 Hz, 576i, 50 Hz, 576p, 50 Hz, 720p, 50,60 Hz, 480i, 60 Hz,
