98BDL4650D/00

4000 Series / D-Line

Philips D-Line is designed to engage your audience and delight customers. Powered by Android 11 for easy software integrations, this versatile display is suitable for impact in any setting.

Size: 98”

98” 86” 75” 65” 50” 43”

Get a quote

Connectivity Toggle

Video output	DisplayPort 1.4
WiFi	WiFi 6 + Bluetooth 5.2
Video input	DVI-I, DisplayPort 1.4, HDMI 2.0, USB 3.0, VGA,
Audio output	3.5mm jack
Audio input	3.5 mm jack
External control	RJ45, RS232C 2.5 mm jack, IR 3.5 mm jack,
Other connections	4G/LTE antenna connectors, Micro USB, USB 2.0,

Convenience Toggle

Tiled Matrix	Up to 10 x 15
Placement	Landscape, Portrait,
Screen saving functions	Pixel Shift
Energy saving functions	Smart Power
Network controllable	RS232, External 4G mPCIe slot, RJ45, WiFi,
Signal loop through	IR Loopthrough, DisplayPort, RS232,
WiFi protocol	a b g n, 802.11 ax, 802.11 ac
Keyboard control	Hidden, Lockable,

Accessories Toggle

Included Accessories	RS232 daisy-chain cable, Philips logo, AC Switch Cover, USB Cover, Screws, AC Power Cord, IR sensor cable, Quick start guide, Remote control & AAA batteries, RS232 cable, WiFi module, Wire Clamper,

Internal Player Toggle

Storage	32 GB eMMc
CPU	2x A72 + 4x A53
GPU	ARM Mali-T860 MP4
Memory	4GB RAM

Dimensions Toggle

Product weight (lb)	144.71 lbs lb
Wall Mount	1000 x 400 mm, M8
Set Depth (inch)	3.46 /3.70 inch
Set Height (inch)	49.42 inch
Bezel width	16.9mm - 20mm bottom
Set Width	2193.4 mm
Set Height	1255.3 mm
Set Depth	87.8 / 94.1 mm
Set Width (inch)	86.35 inch
Product weight	65.64 kg

Sound

Built-in speakers	2 x 10W RMS

Power

Energy Label Class	G
Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
Standby power consumption	<0.5 W
Consumption (Typical)	209 W

Multimedia Applications Toggle

USB Playback Picture	BMP, JPEG, PNG,
USB Playback Video	MPEG, H.263, H.264, H.265, AVI, MP4, MPEG4, VP8, VP9, WEBM,
USB Playback Audio	AAC, HEAAC, MPEG,

Miscellaneous Toggle

On-Screen Display Languages	English, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish,
Warranty	3 year warranty
Regulatory approvals	CE, RoHS, CB, EMF, FCC, Class A, UL,

Operating conditions Toggle

Temperature range (storage)	-20 ~ 60 °C
Humidity range (operation)[RH]	20 - 80% RH
Humidity range (storage) [RH]	5 - 95% RH
Altitude	0 ~ 3000 m
Temperature range (operation)	0 ~ 40 °C
MTBF	50,000 hour

Picture/Display Toggle

Diagonal screen size (metric)	247.7 cm
Operating system	Android 11
Response time (typical)	8 ms
Pixel pitch	0.56 x 0.56 [mm]
Dynamic contrast ratio	500,000:1
Picture enhancement	3/2 - 2/2 motion pull down, Motion compens. deinterlacing, Dynamic contrast enhancement, Progressive scan,
Panel resolution	3840 x 2160
Contrast ratio (typical)	1200:1
Viewing angle (vertical)	178 degree
Viewing angle (horizontal)	178 degree
Diagonal screen size (inch)	97.5 inch
Brightness	500 cd/m²
Optimum resolution	3840 x 2160 @ 60 Hz
Display colors	1.07 Billion
Panel technology	ADS
Haze	25%
Aspect ratio	16:9

Supported Display Resolution Toggle

Video formats	1080p, 50, 60Hz, 1080i, 50, 60Hz, 480i, 60Hz, 480p, 60Hz, 576i, 50Hz, 576p, 50Hz, 720p, 50,60 Hz, 2160p, 50, 60Hz,
Computer formats	1920 x 1080, 60Hz, 1280 x 1024, 60Hz, 1024 x 768, 60Hz, 1280 x 720, 60Hz, 1440 x 900, 60 Hz, 1600 x 900, 60Hz, 1680 x 1050, 60Hz, 3840 x 2160, 30, 60Hz, 640 x 480, 60Hz, 800 x 600, 60Hz,
