28HDL5000PP/00

5000 Series / L-Line

Empower uniquely crafted Public LED displays that redefine audience engagement. Deliver your immersive visual experiences with seamless connectivity, variable sizing and customisable curvature, allowing you to design a breathtaking display.

Size: 28”

44” 28”

Get a quote

Convenience Toggle

Power loop through	- for 230 V environments: 8 cabinets or fewer - for 110 V environments: 4 cabinets or fewer
Signal control loop through	RJ45
Ease of installation	Guide pins, Light weight, Locking mechanism for cabinet,

Accessories Toggle

QSG	1 pcs
LAN cable (RJ45, CAT-5)	1 pcs

Cabinet

Cabinet diagonal (inch)	27.84
Data connector	RJ45
Cabinet construction	Die-cast aluminium
Cabinet area (m2)	0.25
Receiving card brand	NovaStar
Weight (kg)	6.3
Power connector	In/Out
Cabinet size (mm)	500 x 500 x 40

Power

Input voltage	AC100~240 V

Specific module 14HDL5019PM/00 Toggle

Brightness before calibration	550 nit
Max. power cons. BC (W/m²)	388 W
Cabinet resolution (W x H)	256 x 256
Module resolution (W x H)	128 x 128
Max. power cons. AC (W/m²)	340 W
Pixel pitch	1.9 mm
Consumption (Typical W/m²)	120 W
Cabinet pixels (Dot)	65,536
Brightness after calibration	≤ 500 nit

Operating conditions Toggle

Temperature range (storage)	-20~50 °C
Humidity range (storage) [RH]	10~85%
LED Lifetime	TBD
Temperature range (operation)	-20~45 °C
Humidity range (operation)[RH]	10~80%

Miscellaneous Toggle

Warranty	2 years
Regulatory approvals	RoHS, EAC, EN61000-3-2, EN61000-3-3, IEC/UL60950, IEC/UL62368, IEC62471, EN55032, EN55035, FCC SDOC, Part 15, Class A,

Picture/Display Toggle

Colour temperature default	6500±500 K
Contrast ratio (typical)	>=3000:1
Viewing angle (vertical)	150 degree
Calibration (brightness/colour)	Supported
Colour temperature adjust range	4000~9500 K
Refresh rate (Hz)	3840 Hz
Placement	Landscape
Viewing angle (horizontal)	150 degree
Aspect ratio	1:1
Three specific modules of pixel pitch	1.9 mm, 2.5 mm and 3.9 mm
Picture enhancement	Wide colour gamut display
Brightness uniformity	>=97%
Frame frequency (Hz)	50 & 60

Specific module 14HDL5039PM/00 Toggle

Pixel pitch	3.9 mm
Max. power cons. BC (W/m²)	340 W
Max. power cons. AC (W/m²)	300 W
Cabinet pixels (Dot)	16,384
Cabinet resolution (W x H)	128 x 128
Module resolution (W x H)	64 x 64
Brightness before calibration	550 nit
Consumption (Typical W/m²)	100 W
Brightness after calibration	≤ 500 nit

Specific module 14HDL5025PM/00 Toggle

Cabinet resolution (W x H)	200 x 200
Brightness before calibration	550 nit
Consumption (Typical W/m²)	100 W
Pixel pitch	2.5 mm
Module resolution (W x H)	100 x 100
Brightness after calibration	≤ 500 nit
Cabinet pixels (Dot)	10.000
Max. power cons. AC (W/m²)	300 W
Max. power cons. BC (W/m²)	340 W
