43BDL3452T/00

3000 Series / T-Line

Inspire collaboration. Deliver information. This responsive Philips Multi-Touch Professional UHD Display is ideal for multi-finger, multi-user applications—from wayfinding to presentations. Up to 20 touch points can be active at once.

Size: 43”

55” 43”

Get a quote

Miscellaneous Toggle

On-Screen Display Languages	Arabic, English, French, German, Italian, Japanese, Polish, Spanish, Turkish, Russian, Simplified Chinese, Traditional Chinese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish,
Warranty	3 year warranty
Regulatory approvals	CE, RoHS, CB, BSMI, FCC, Class A, CU, ETL, IMDA, PSB,

Picture/Display Toggle

Pixel pitch	0.2451 x 0.2451 mm
Panel resolution	3840 x 2160
Viewing angle (horizontal)	178 degree
Aspect ratio	16:9
Brightness	400 cd/m²
Diagonal screen size (metric)	108.0 cm
Contrast ratio (typical)	1200:1
Diagonal screen size (inch)	43 inch
Viewing angle (vertical)	178 degree
Display colours	1.07 B
Picture enhancement	3/2 - 2/2 motion pull down, 3D Combfilter, Motion compens. deinterlacing, Progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement,
Surface treatment	Anti-Glare coating
Optimum resolution	3840 x 2160 @ 60 Hz
Panel technology	IPS
Response time (typical)	8 ms
Operating system	Android 8.0

Operating conditions Toggle

Altitude	0 ~ 3000 m
Temperature range (storage)	-20 ~ 60 °C
MTBF	50,000 hour
Humidity range (operation)[RH]	20–80%
Temperature range (operation)	0 ~ 40 °C
Humidity range (storage) [RH]	5–95%

Supported Display Resolution Toggle

Video formats	480i, 60 Hz, 480p, 60 Hz, 576p, 50 Hz, 576i, 50 Hz, 720p, 50, 60 Hz, 1080i, 50, 60 Hz, 1080p, 50, 60 Hz, 1080i, 25, 30 Hz, 3840 x 2160, 24, 25 Hz, 3840 x 2160, 30Hz, 480i, 30, 60 Hz, 576i, 25, 50 Hz,
Computer formats	640 x 480, 60, 67, 72, 75 Hz, 800 x 600, 56, 60, 72, 75 Hz, 1024 x 768, 60 Hz, 1280 x 768, 60 Hz, 1280 x 800, 60 Hz, 1280 x 1024, 60 Hz, 1360 x 768, 60 Hz, 1366 x 768, 60 Hz, 1440 x 900, 60 Hz, 1600 x 1200, 60 Hz, 1920 x 1080, 60 Hz, 1920 x 1200, 60 Hz, 3840 x 2160, 60 Hz, 50 Hz, 720 x 400, 70 Hz, 800 x 600, 60, 72, 75 Hz,

Interactivity Toggle

Plug and play	HID compliant
Protection glass	3 mm tempered safety glass
Touchpoints	20 simultaneous touch points
Multi-touch technology	IRHE

Connectivity Toggle

Audio output	3.5 mm jack
Other connections	micro SD, OPS,
Video input	DVI-D, HDMI 2.0, USB 2.0 Type A, USB 2.0 Type B, VGA,
External control	RJ45, IR 3.5 mm jack, RS232C 2.5 mm jack,
Audio input	3.5 mm jack

Convenience Toggle

Remote control signal	Lockable
Network controllable	RS232, RJ45,
Signal loop through	RS232, IR Loop through,
Energy-saving functions	Smart Power
Keyboard control	Hidden, Lockable,
Placement	Landscape, Portrait,
Screen-saving functions	Pixel Shift, Low Brightness

Accessories Toggle

Stand	BM05922
Included Accessories	Cleaning cloth, IR sensor cable, Philips logo, Power supply cable, Quick start guide, Remote control and AAA batteries, RS232 cable, RS232 daisy chain cable, USB Cover and screw x 1,

Dimensions Toggle

Set Depth	75.3/109.2 mm
Wall Mount	200 x 200 mm, M6
Set Height	592.6 mm
Set Height (inch)	23.33 inch
Set Width	1004.4 mm
Set Width (inch)	39.54 inch
Product weight (lb)	40.87 lb
Bezel width	16.3 mm
Set Depth (inch)	2.96/4.30 inch
Product weight	18.54 kg

Internal Player Toggle

GPU	ARM Mali G51
Memory	2 GB DDR3, 8 GB,
CPU	2 x A53 + 2 x A73
Wi-Fi	2.4 G, 5 G,

Sound

Built-in speakers	2 x 10 W

Power

Consumption (Typical)	100 W
Energy Label Class	G
Power Saving Features	Smart Power
Consumption (Max)	220 W
Mains power	100 ~ 240 VAC, 50/60 Hz
Standby power consumption	<0.5 W

Multimedia Applications Toggle

USB Playback Picture	BMP, GIF, JPEG, JPG, PDF,
USB Playback Video	M2TS, M4V, MK3D, MKV, MP4, MPEG, MPG, MTS, TS, TTS, VOB, WMV,
USB Playback Audio	AAC, AIF, AIFF, ASF, LPCM, M3U, M4A, MP3, MP4, WAV, WMA,
