86BDL4511D/00

4000 Series / D-Line

Make it stand out with a fast Philips D-Line Professional 4K UHD display. Philips superb picture quality ensures true colors and intense contrast. You can effortlessly display content from multiple sources on a single screen.

Size: 86”

86” 75” 65” 55” 50” 43” 32”

Get a quote

Connectivity Toggle

Audio output	3.5mm jack
Video input	Display Port1.2, DVI-I, HDMI 2.0, USB 2.0,
External control	IR 3.5 mm jack, RJ45, RS232C 2.5 mm jack,
Video output	DisplayPort 1.2, HDMI 2.0,
Other connections	OPS
Audio input	3.5 mm jack

Convenience Toggle

Energy saving functions	Smart Power
Signal loop through	DisplayPort, RS232, HDMI, IR Loopthrough,
Keyboard control	Hidden, Lockable,
Screen saving functions	Pixel Shift, Low Bright
Placement	Landscape, Portrait,
Network controllable	RS232, RJ45,

Accessories Toggle

Included Accessories	AC Switch Cover, Philips logo, RS232 daisy-chain cable, AC power cord, IR sensor cable, Quick start guide, Remote control & AAA batteries, RS232 cable, USB Cover and screw x1, Wire Clamper,

Dimensions Toggle

Set Height	1100.0 mm
Set Width (inch)	75.94 inch
Set Depth (inch)	2.74 / 3.61 inch
Product weight (lb)	110.67 lb
Set Depth	69.5 /91.8 mm
Set Width	1929.0 mm
Set Height (inch)	43.31 inch
Product weight	50.24 kg
Bezel width	15.5 mm
Wall Mount	600x400 mm, M8

Sound

Built-in speakers	2 x 10W RMS

Power

Consumption (Max)	560 W
Standby power consumption	<0.5 W
Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
Energy Label Class	G
Consumption (Typical)	355 W

Multimedia Applications Toggle

USB Playback Video	H.263, H.264, H.265, MPEG,
USB Playback Picture	BMP, JPEG, PNG,
USB Playback Audio	AAC, MPEG, HEAAC,

Miscellaneous Toggle

On-Screen Display Languages	Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese,
Warranty	3 year warranty
Regulatory approvals	CE, FCC, Class A, CCC, RoHS, CB, BSMI, EMF, VCCI, PSB, ETL, CECP, EAC,

Operating conditions Toggle

Temperature range (operation)	0 ~ 40 °C
Altitude	0 ~ 3000 m
Humidity range (storage) [RH]	5 - 95% RH
Humidity range (operation)[RH]	20 - 80% RH
MTBF	50,000 hour
Temperature range (storage)	-20 ~ 60 °C

Picture/Display Toggle

Diagonal screen size (inch)	85.6 inch
Contrast ratio (typical)	1200:1
Aspect ratio	16:9
Dynamic contrast ratio	500,000:1
Viewing angle (horizontal)	178 degree
Panel resolution	3840 x 2160
Optimum resolution	3840 x 2160 @60HZ
Response time (typical)	8 ms
Brightness	500 cd/m²
Diagonal screen size (metric)	217.4 cm
Display colors	1.07 Billion
Pixel pitch	0.4935 x 0.4935 mm
Panel technology	IPS
Viewing angle (vertical)	178 degree
Haze	25%

Supported Display Resolution Toggle

Computer formats	640 x 480, 60Hz, 800 x 600, 60Hz, 1024 x 768, 60Hz, 1280 x 720, 60Hz, 1280 x 1024, 60Hz, 1440 x 900, 60 Hz, 1600 x 900, 60Hz, 1680 x 1050, 60Hz, 1920 x 1080, 60Hz, 3840 x 2160, 30, 60Hz,
Video formats	480i, 60Hz, 480p, 60Hz, 576p, 50Hz, 576i, 50Hz, 720p, 50,60 Hz, 1080i, 50, 60Hz, 1080p, 50, 60Hz, 2160p, 24, 30, 60Hz,
