86BDL4511D/00

4000 Series / D-Line

Make it stand out with a fast Philips D-Line Professional 4K UHD display. Philips superb picture quality ensures true colors and intense contrast. You can effortlessly display content from multiple sources on a single screen.

Size: 86”

86” 75” 65” 55” 50” 43” 32”

Get a quote

Connectivity Toggle

Audio output	3.5mm jack
Other connections	OPS
Audio input	3.5 mm jack
External control	IR 3.5 mm jack, RJ45, RS232C 2.5 mm jack,
Video input	Display Port1.2, DVI-I, HDMI 2.0, USB 2.0,
Video output	DisplayPort 1.2, HDMI 2.0,

Convenience Toggle

Network controllable	RS232, RJ45,
Keyboard control	Hidden, Lockable,
Placement	Landscape, Portrait,
Signal loop through	DisplayPort, RS232, HDMI, IR Loopthrough,
Energy saving functions	Smart Power
Screen saving functions	Pixel Shift, Low Bright

Accessories Toggle

Included Accessories	AC Switch Cover, Philips logo, RS232 daisy-chain cable, AC power cord, IR sensor cable, Quick start guide, Remote control & AAA batteries, RS232 cable, USB Cover and screw x1, Wire Clamper,

Dimensions Toggle

Set Width	1929.0 mm
Product weight	50.24 kg
Bezel width	15.5 mm
Set Depth (inch)	2.74 / 3.61 inch
Product weight (lb)	110.67 lb
Set Height (inch)	43.31 inch
Set Height	1100.0 mm
Wall Mount	600x400 mm, M8
Set Width (inch)	75.94 inch
Set Depth	69.5 /91.8 mm

Sound

Built-in speakers	2 x 10W RMS

Power

Energy Label Class	G
Standby power consumption	<0.5 W
Consumption (Max)	560 W
Consumption (Typical)	355 W
Mains power	100 ~ 240 VAC, 50 ~ 60 Hz

Multimedia Applications Toggle

USB Playback Video	H.263, H.264, H.265, MPEG,
USB Playback Picture	BMP, JPEG, PNG,
USB Playback Audio	AAC, MPEG, HEAAC,

Operating conditions Toggle

Temperature range (storage)	-20 ~ 60 °C
Humidity range (operation)[RH]	20 - 80% RH
Temperature range (operation)	0 ~ 40 °C
MTBF	50,000 hour
Humidity range (storage) [RH]	5 - 95% RH
Altitude	0 ~ 3000 m

Miscellaneous Toggle

Regulatory approvals	CE, FCC, Class A, CCC, RoHS, CB, BSMI, EMF, VCCI, PSB, ETL, CECP, EAC,
On-Screen Display Languages	Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese,
Warranty	3 year warranty

Picture/Display Toggle

Diagonal screen size (metric)	217.4 cm
Aspect ratio	16:9
Diagonal screen size (inch)	85.6 inch
Haze	25%
Viewing angle (vertical)	178 degree
Display colors	1.07 Billion
Viewing angle (horizontal)	178 degree
Panel technology	IPS
Optimum resolution	3840 x 2160 @60HZ
Pixel pitch	0.4935 x 0.4935 mm
Panel resolution	3840 x 2160
Contrast ratio (typical)	1200:1
Brightness	500 cd/m²
Dynamic contrast ratio	500,000:1
Response time (typical)	8 ms

Supported Display Resolution Toggle

Computer formats	640 x 480, 60Hz, 800 x 600, 60Hz, 1024 x 768, 60Hz, 1280 x 720, 60Hz, 1280 x 1024, 60Hz, 1440 x 900, 60 Hz, 1600 x 900, 60Hz, 1680 x 1050, 60Hz, 1920 x 1080, 60Hz, 3840 x 2160, 30, 60Hz,
Video formats	480i, 60Hz, 480p, 60Hz, 576p, 50Hz, 576i, 50Hz, 720p, 50,60 Hz, 1080i, 50, 60Hz, 1080p, 50, 60Hz, 2160p, 24, 30, 60Hz,
