43BDL3650QE/00

3000 Series / QE-Line

Engage your audience with this environmentally conscious 4K Ultra HD digital display. Delivering uncompromised 4K UHD performance while running on half the power compared to other market models, with the very latest PPDS EcoDesign.

Size: 43”

65” 55” 50” 43”

Get a quote

Connectivity Toggle

Video input	HDMI 2.0, DVI-I, USB 2.0, USB 3.0,
Optional WiFi functionality	CRD22 Wi-Fi dongle
Audio output	3.5 mm jack
Other connections	micro SD
Audio input	3.5 mm jack
External control	RJ45, RS232C 2.5 mm jack, IR 3.5 mm jack,

Convenience Toggle

Placement	Landscape, Portrait,
Remote control signal	Lockable
Energy-saving functions	Smart Power
Keyboard control	Lockable, Hidden,
Signal loop through	RS232, IR Loop through,
Network controllable	RS232, RJ45,
Tiled Matrix	Up to 15 x 15

Accessories Toggle

Included Accessories	IR sensor cable, RS232 daisy-chain cable, Philips logo, AC Power Cord, AC Switch Cover, Cable clip, Quick start guide, RS232 cable, USB Cover,

Internal Player Toggle

Memory	16 GB, 3 GB DDR,
CPU	Quad-Core Cortex A55
GPU	G52 MC1

Dimensions Toggle

Set Width	973.0 mm
Set Height	561.2 mm
Wall Mount	200 mm x 200 mm, M6
Set Width (inch)	38.31 inch
Product weight (lb)	24.91 lb
Bezel width	13.9 mm
Product weight	11.29 kg
Set Depth (inch)	2.50 inch
Set Height (inch)	22.09 inch
Set Depth	63.5 mm

Sound

Built-in speakers	2 x 10 W RMS

Power

Energy Label Class	E
Power Saving Features	Smart Power
Consumption (Max)	102 W
Mains power	100–240 V~, 50/60 Hz
Standby power consumption	<0.5 W
Consumption (Typical)	53 W

Multimedia Applications Toggle

USB Playback Video	H.263, H.264, H.265, MPEG1/2, MPEG4, VP8, VP9,
USB Playback Picture	JPEG, BMP, PNG,
USB Playback Audio	AAC, HEAAC, MPEG,

Operating conditions Toggle

Altitude	0 ~ 3000 m
Humidity range (operation)[RH]	20~80% RH
Temperature range (operation)	0 ~ 40 °C
Temperature range (storage)	-20 ~ 60 °C
Humidity range (storage) [RH]	5~95% RH
MTBF	30,000 hour

Miscellaneous Toggle

Regulatory approvals	CE, CB, BSMI, FCC, Class A, VCCI, J-Moss, ETL, RoHS,
On-Screen Display Languages	English, French, German, Italian, Polish, Russian, Spanish, Turkish, Simplified Chinese, Traditional Chinese, Arabic, Japanese,
Warranty	3 year warranty

Picture/Display Toggle

Optimum resolution	3840 x 2160 @ 60 Hz
Picture enhancement	3/2 - 2/2 motion pull down, Dynamic contrast enhancement, Motion compens. deinterlacing, Progressive scan,
Pixel pitch	0.2854 x 0.2854 mm
Panel resolution	3840 x 2160
Display colours	1.06 Billion
Brightness	350 cd/m²
Diagonal screen size (metric)	125.7 cm
Response time (typical)	8 ms
Panel technology	VA
Operating system	Android 10
Contrast ratio (typical)	4000:1
Diagonal screen size (inch)	49.5 inch
Viewing angle (vertical)	178 degree
Viewing angle (horizontal)	178 degree
Dynamic contrast ratio	500,000:1
Aspect ratio	16:9

Supported Display Resolution Toggle

Video formats	1080p, 50, 60 Hz, 1080i, 50, 60 Hz, 3840 x 2160p, 24, 25, 30, 60 Hz, 480i, 60 Hz, 480p, 60 Hz, 720p, 50,60 Hz,
Computer formats	832 x 624, 75 Hz, 1024 x 768, 60, 70, 75 Hz, 1152 x 864, 75 Hz, 1152 x 870, 75 Hz, 1280 x 1024, 60 Hz, 1280 x 720, 60 Hz, 1280 x 800, 60 Hz, 1440 x 900, 60 Hz, 1600 x 1200, 60 Hz, 1680 x 1050, 60 Hz, 1920 x 1080, 60 Hz, 3840 x 2160, 24, 25, 30, 60 Hz, 640 x 480, 60, 67, 72, 75 Hz, 720 x 400, 70 Hz, 800 x 600, 56, 60, 72, 75 Hz,
