Made for results
Q-Line
Versatile signage
- CMND & Control
- Integrated Media Player
- FailOver
- CMND & Create
- Android SoC
- HTML5 browser
Ultimate attention
Q-Line makes your content the focal point in any space.
Connectivity
| Video input | HDMI 2.0, USB 2.0, DVI-I, |
|---|---|
| Audio input | 3.5 mm jack |
| External control | RJ45, RS232C 2.5 mm jack, IR 3.5 mm jack, |
| Audio output | 3.5 mm jack |
Convenience
| Placement | Landscape, Portrait, |
|---|---|
| Network controllable | RS232, RJ45, |
| Tiled Matrix | Up to 15 x 15 |
| Signal loop through | RS232, IR Loop through, |
| Energy-saving functions | Smart Power |
| Keyboard control | Lockable, Hidden, |
| Start-up | Switch on delay, Switch on status, Boot on source, |
| Remote control signal | Lockable |
| Start-up window | enable/disable Philips logo |
Accessories
| Stand | BM02541/BM05911 |
|---|---|
| Included Accessories | IR sensor cable, RS232 daisy-chain cable, Philips logo, USB Cover and screw, |
| Included accessories | AC Power Cord, RS232 cable, Remote Control, Batteries for remote control, Quick start guide, |
Internal Player
| GPU | ARM Mali G51 |
|---|---|
| Memory | 2 GB DDR3, 8 GB, |
| CPU | Dual core cortex A53 1.1 GHz, Dual core cortex A73 1.15 GHz, |
Dimensions
| Set Depth | 69.1/65.1 mm |
|---|---|
| Set Height (inch) | 16.75 inch |
| Set Width | 726.5 mm |
| Product weight | 5.31 kg |
| Set Depth (inch) | 2.72/2.56 inch |
| Bezel width | 11.9/17.2 mm |
| Set Width (inch) | 28.6 inch |
| Set Height | 425.4 mm |
| Product weight (lb) | 11.71 lb |
| Wall Mount | 100 mm x 100 mm, 200 mm x 200 mm, M4 |
Sound
| Built-in speakers | 2 x 10 W RMS |
|---|
Power
| Consumption (Typical) | 50 W |
|---|---|
| Energy Label Class | G |
| Standby power consumption | <0.5 W |
| Mains power | 100-240 V~, 50-60 Hz, 1.5 A |
| Consumption (Max) | 80 W |
| Power Saving Features | Smart Power |
Multimedia Applications
| USB Playback Audio | AAC, HEAAC, MPEG, |
|---|---|
| USB Playback Video | MPEG, H.264, H.263, H.265, |
| USB Playback Picture | BMP, JPEG, PNG, |
Miscellaneous
| Regulatory approvals | CB, CE, BSMI, CU, EPA, ETL, FCC, Class A, VCCI, J-Moss, |
|---|---|
| Warranty | 3 year warranty |
| On-Screen Display Languages | English, French, German, Italian, Polish, Turkish, Russian, Simplified Chinese, Spanish, Traditional Chinese, Arabic, Japanese, |
Picture/Display
| Optimum resolution | 1920 x 1080 @ 60 Hz |
|---|---|
| Aspect ratio | 16:9 |
| Viewing angle (horizontal) | 178 degree |
| Dynamic contrast ratio | 500,000:1 |
| Diagonal screen size (inch) | 31.5 inch |
| Viewing angle (vertical) | 178 degree |
| Picture enhancement | 3/2 - 2/2 motion pull down, 3D Combfilter, 3D MA deinterlacing, Dynamic contrast enhancement, Motion compens. deinterlacing, Progressive scan, |
| Display colours | 16.7 Million |
| Contrast ratio (typical) | 4000:1 |
| Response time (typical) | 8 ms |
| Panel technology | VA |
| Operating system | Android 8.0 |
| Clinical image | D-Image preset |
| Brightness | 350 cd/m² |
| Pixel pitch | 0.36375 x 0.36375 mm |
| Panel resolution | 1920 x 1080p |
| Diagonal screen size (metric) | 80 cm |
Operating conditions
| Humidity range (operation)[RH] | 20~80% RH |
|---|---|
| Altitude | 0 ~ 3000 m |
| MTBF | 30,000 hour |
| Temperature range (operation) | 0 ~ 40 °C |
| Humidity range (storage) [RH] | 5~95% RH |
| Temperature range (storage) | -20 ~ 60 °C |
Supported Display Resolution
| Computer formats | 1920 x 1080, 60 Hz, 1680 x 1050, 60 Hz, 1600 x 1200, 60 Hz, 1440 x 900, 60 Hz, 1280 x 1024, 60 Hz, 1280 x 800, 60 Hz, 1280 x 720, 60 Hz, 1152 x 870, 75 Hz, 1024 x 768, 60, 70, 75 Hz, 800 x 600, 56, 60, 72, 75 Hz, 720 x 400, 70 Hz, 640 x 480, 60, 67, 72, 75 Hz, 1152 x 864, 75 Hz, 832 x 624, 75 Hz, |
|---|---|
| Video formats | 576p, 50 Hz, 576i, 50 Hz, 480p, 60 Hz, 480i, 60 Hz, 1080p, 50, 60 Hz, 1080i, 50, 60 Hz, 3840 x 2160, 30Hz, 3840 x 2160, 60 Hz, 720p, 50,60 Hz, |
