32BDL3510Q/00

3000 Series / Q-Line

Inform and enthral with a Philips Q-Line Professional Full HD Display. This reliable solution can be up and running as quickly as you need.

Size: 32”

Q-Line makes your content the focal point in any space.

Connectivity Toggle

Convenience Toggle

Start-up window	enable/disable Philips logo
Remote control signal	Lockable
Energy-saving functions	Smart Power
Signal loop through	RS232, IR Loop through,
Keyboard control	Lockable, Hidden,
Placement	Landscape, Portrait,
Start-up	Switch on delay, Switch on status, Boot on source,
Network controllable	RS232, RJ45,
Tiled Matrix	Up to 15 x 15

Accessories Toggle

Included Accessories	IR sensor cable, RS232 daisy-chain cable, USB Cover, USB Cover and screw,
Stand	BM02541/BM05911
Included accessories	AC Power Cord, RS232 cable, Remote Control, Batteries for remote control, Quick start guide,

Dimensions Toggle

Sound

Built-in speakers	2 x 10 W RMS

Power

Multimedia Applications Toggle

Miscellaneous Toggle

Regulatory approvals	CB, CE, BSMI, CU, EPA, ETL, FCC, Class A, VCCI,
On-Screen Display Languages	English, French, German, Italian, Polish, Turkish, Russian, Simplified Chinese, Spanish, Traditional Chinese, Arabic, Japanese,
Warranty	3 year warranty

Picture/Display Toggle

Picture enhancement	3/2 - 2/2 motion pull down, 3D Combfilter, 3D MA deinterlacing, Dynamic contrast enhancement, Motion compens. deinterlacing, Progressive scan,
Display colours	16.7 Million
Contrast ratio (typical)	4000:1
Optimum resolution	1920 x 1080 @ 60 Hz
Diagonal screen size (metric)	80 cm
Clinical image	D-Image preset
Brightness	350 cd/m²
Viewing angle (vertical)	178 degree
Panel technology	VA
Response time (typical)	6.5 ms
Pixel pitch	0.36375 x 0.36375 mm
Panel resolution	1920 x 1080p
Diagonal screen size (inch)	31.5 inch
Dynamic contrast ratio	500,000:1
Aspect ratio	16:9
Viewing angle (horizontal)	178 degree

Operating conditions Toggle

Temperature range (storage)	-20 ~ 60 °C
Humidity range (operation)[RH]	20~80% RH
Temperature range (operation)	0 ~ 40 °C
Humidity range (storage) [RH]	5~95% RH
Altitude	0 ~ 3000 m
MTBF	50,000 hour

Supported Display Resolution Toggle

Video formats	720p, 60 Hz, 576p, 50 Hz, 576i, 50 Hz, 480p, 60 Hz, 480i, 60 Hz, 1080i, 50, 60 Hz, 1080p, 50, 60 Hz,
Computer formats	1920 x 1080, 60 Hz, 1680 x 1050, 60 Hz, 1600 x 1200, 60 Hz, 1440 x 900, 60 Hz, 1280 x 1024, 60 Hz, 1280 x 800, 60 Hz, 1280 x 720, 60 Hz, 1152 x 870, 75 Hz, 1024 x 768, 60, 70, 75 Hz, 800 x 600, 56, 60, 72, 75 Hz, 720 x 400, 70 Hz, 640 x 480, 60, 67, 72, 75 Hz, 1152 x 864, 75 Hz, 832 x 624, 75 Hz,
