55BDL2105X/27

2000 Series / X-Line

Designed for 24/7 operation, the Philips X-Line Videowall display captivates customer attention with its immersive moving content. CMND makes managing your promotions and retail content easy, whilst FailOver adds greater peace of mind.

Size: 55”

Get a quote

Made for results

TAA compliant

Created in 1979, TAA compliance requires products and goods considered for governmental use to be manufactured or substantially transformed in the US or in designated TAA countries*. Products for government use are available via selected commercial companies – such as distributors – with Federal Supply Schedule government contracts.

Connectivity Toggle

Audio output	3.5 mm Mini Jack
Other connections	OPS, USB 2.0, Thermal sensor,
Video input	Display Port1.2, DVI-D, HDMI 2.0, VGA,
Audio input	3.5 mm mini jack
External control	IR 3.5 mm jack, LAN RJ45,
Video output	DisplayPort 1.2

Convenience Toggle

Screen saving functions	Pixel Shift, Low Bright
Tiled Matrix	Up to 15 x 15
Energy saving functions	Smart Power
Ease of installation	Carrying Handles, Smart Insert,
Signal loop through	DisplayPort, RJ45,
Placement	Landscape, Portrait,
Network controllable	LAN

Accessories Toggle

Included Accessories	Gap pad x3, IR sensor cable, Quick start guide, Remote control & AAA batteries, RJ45 / RS232 converter, Wire Clamper, Power cord, DP cable, RJ45 cable, Edge alignment pin, Kit-1, Kit-2,

Dimensions Toggle

Set Width	1213.5 mm
Product weight	28.8 kg
Set Height	684.3 mm
Wall Mount	400mm x 400mm, M6
Set Depth (inch)	3.85/3.85 inch
Smart Insert mount	100mm x 100mm, 6xM4xL6
Bezel width	2.3 mm + 1.2 mm
Set Height (inch)	26.94 inch
Set Depth	97.8 mm/97.8 mm mm
Set Width (inch)	47.77 inch

Sound

Built-in speakers	2 x 10W

Power

Consumption (On mode)	140 W
Standby power consumption	0.5 W
Consumption (Max)	340 W
Consumption (Typical)	180 W
Energy Label Class	G

Operating conditions Toggle

MTBF	50,000 hour
Humidity range (operation)[RH]	20 - 80%
Altitude	0 ~ 3000 m
Humidity range (storage) [RH]	5 - 95%
Temperature range (storage)	-20 ~ 60 °C
Temperature range (operation)	0 ~ 40 °C

Miscellaneous Toggle

On-Screen Display Languages	Arabic, English, French, German, Italian, Japanese, Polish, Russian, Spanish, Simplified Chinese, Turkish, Traditional Chinese,
Warranty	3 years warranty
Regulatory approvals	CE, FCC, Class A, RoHS, CB, ETL, BSMI,

Picture/Display Toggle

Viewing angle (vertical)	178 degree
Response time (typical)	8 ms
Viewing angle (horizontal)	178 degree
Contrast ratio (typical)	1200:1
Optimum resolution	1920 x 1080 @ 60 Hz
Haze	25 %
Diagonal screen size (inch)	54.5 inch
Dynamic contrast ratio	500,000:1
Aspect ratio	16:9
Diagonal screen size (metric)	138.7 cm
Display colors	16.7 M
Panel resolution	1920x1080p
Pixel pitch	0.63 x 0.63 mm
Brightness	500 cd/m²

Supported Display Resolution Toggle

Computer formats	720 x 400, 70Hz, 800 x 600, 60, 75Hz, 1024 x 768, 60, 75Hz, 1280 x 768, 60Hz, 1280 x 800, 60Hz, 1280 x 960, 60Hz, 1280 x 1024, 60Hz, 1360 x 768, 60Hz, 1366 x 768, 60Hz, 1600 x 1200, 60Hz, 1920 x 1080, 60Hz, 640 x 480, 60, 72, 75Hz,
Video formats	720p, 50, 60Hz, 1080i, 25, 30Hz, 1080p, 50, 60Hz, 2160P 50, 60Hz,
